Topics Covered:
This lesson draws on the same principles as the wall- you are checking for a collision between JumpMan and a variable that is randomly placed.
/*
* Here you'll add a new game element, a heart, which will add a life to
* the player's total if they get collide with it in a jump.
* Hearts will show up randomly.
*
* The decision of whether a heart will show up will be based on another
* 'state variable' that will be set to 0 or 1 at each game level.
*/
#include "MakerScreenXVI.h"
MakerScreenXVI lcd;
byte run0[8] = { //legs in partial stride
0b00000,
0b01100,
0b01100,
0b01100,
0b01110,
0b01100,
0b01010,
0b01010
};
byte run1[8] = { //legs in full stride
0b00000,
0b01100,
0b01100,
0b01111,
0b01100,
0b01100,
0b01010,
0b10001
};
byte wall[8] = { //wall obstacle
0b11111,
0b10101,
0b11111,
0b10001,
0b11111,
0b10101,
0b11111,
0b10001
};
byte crash[8] = { //crashed JumpMan
0b00000,
0b00011,
0b01011,
0b00111,
0b00011,
0b00011,
0b00001,
0b00001
};
byte jump[8] = { //mid-jump icon
0b00110,
0b10110,
0b01100,
0b01111,
0b01110,
0b01011,
0b10000,
0b00000
};
// Make an icon for the heart object, just like the others
byte heart[8] = {//heart for extra life
0b00000,
0b01010,
0b10101,
0b10001,
0b01010,
0b00100,
0b00000,
0b00000
};
int position = 0; //holds the changing position of the cursor
bool runState = 0; //which running animation to draw (0 or 1).
int jumpState = 0; //0 ='pre-jump', 1 ='mid jump', 2='post jump'
bool buttonState = 0; //will equal 1 after press, 0 after jump completed
int wallPosition = 14; //wall can be placed from 0 to 15
int lives = 3; //starting number of lives
int animationDuration = 300;//ms between animations of JumpMan's legs
int runDuration = 600; //ms between moving JumpMan's position on the screen
//Timers to update for each 'level'
long animationTimer;
long runTimer;
bool heartState = 0;//0 = no heart available, 1 = heart available
int heartPosition; //which column is the heart in?
void setup() {
lcd.begin();
lcd.backlightOn();
lcd.createChar(0, run0); //partial stride character
lcd.createChar(1, run1); //full stride character
lcd.createChar(2, wall); //wall character in 'slot' 2 of custom characters
lcd.createChar(3, crash); //splatted character against the wall
lcd.createChar(4, jump); //mid-jump icon
lcd.createChar(5, heart); //heart for extra lives
pinMode(6,INPUT_PULLUP); //button to trigger jump
startScreen();//run function for welcome screen
//Start both timers equal to millis() so that the difference between
//millis and the variables is 0.
animationTimer = millis();
runTimer = millis();
/*
* randomSeed() is a built-in function for Arduino that takes a
* reading from a pin and uses that reading to create a random number.
* Without it, Maker Board will use the same pattern of 'random'
* numbers. randomSeed solves that problem.
*/
randomSeed(analogRead(A0));//take a reading from A0 to get a random number
}
void loop() {
lcd.setCursor(0,0);
lcd.write(4); //Show the jump icon alongside the lives counter
lcd.print(lives);
//Set the cursor depending on the state of the character
if (jumpState == 0){
lcd.setCursor(position,1);
}
else if (jumpState == 1){
lcd.setCursor(position,0);
}
else if (jumpState == 2){
lcd.setCursor(position,1);
}
if (jumpState == 1){ //if jump has been activated..
lcd.write(4); //draw JumpMan mid-air
}
else{
lcd.write(runState); //draw the run0 or run1 animation
}
lcd.setCursor(wallPosition,1);
lcd.write(2); //draw wall
// Draw the heart right after drawing the wall, but only
// if heartState is 1- if there is currently one available.
if (heartState == 1){
lcd.setCursor(heartPosition,0);
lcd.write(5); //heart icon
}
if ((digitalRead(6) == LOW)&&(jumpState == 0)){
buttonState = 1; //1 means a press is recorded
}
//Button is unpressed and a jump has been completed
if ((digitalRead(6) == HIGH)&&(jumpState == 2)){
jumpState = 0;
}
if (millis() - animationTimer > animationDuration){
runState = 1 - runState; //draw the next JumpMan animation
animationTimer = millis();
lcd.clear(); //clear the LCD to draw a new character
}
if (millis() - runTimer > runDuration){//update position after runDuration
position = position + 1;
/*
* In the 'if' block that resets the runner to the left of the
* screen, use random() to decide if a heart will be available
*/
if (position == 16){
heartState = 0; //by default there is no heart available
if (random(0,10) < 3){//30% of the time...
heartState = 1; //signal that a heart will be available
heartPosition = random(3,16); // Place the heart randomly
}
wallPosition = random(3,16); //place wall in column 3 through 15
position = 0;
}
//if button has been pressed and a jump hasn't been initiated...
if ((buttonState == 1)&&(jumpState == 0)){
jumpState = 1; //signal a jump
buttonState = 0; //reset button to 'unpressed' in the code
}
else if (jumpState == 1){ //true if jumpState set to one in the last loop
jumpState = 2; //jump is marked as complete
}
/*
* Just like checking for a collision with a wall, check for
* a collision with a heart if one is available.
*/
if ((position == heartPosition)&&(jumpState == 1)){
if (heartState == 1){
lives = lives + 1; //add a life
heartState = 0; //reset the heart variable
}
}
if ((position == wallPosition)&&(jumpState != 1)){//if a jump is missed...
drawCrash();
lives = lives - 1;//decrease lives by one with each crash
/*
* If the player has run out of lives, print a message to the screen
* and reset the game.
*/
if (lives == 0){ //if out of lives...
// Clear the LCD and write "Game Over" to it
lcd.clear();
lcd.setCursor(4,0);
lcd.print("Game Over");
delay(2000);//wait two seconds to restart the game
//Reset all state variables:
lives = 3;
position = 0;
buttonState = 0;
runState = 0;
//Reset speeds to 'level one'
runDuration = 600;
animationDuration = 300;
/*
* Show the start screen after the 'game over' is shown so that the
* next game won't start until the button is pressed again
*/
startScreen();
}
}
else if (position == wallPosition){//if the jump is successful...
runDuration = runDuration - 50; //speed each position up by 50 ms
if (runDuration < 100){//keep runDuration at a minimum of 100
runDuration = 100;
}
animationDuration = runDuration/2; //Move legs twice per position change
}
lcd.clear();
runTimer = millis();
}
}
void drawCrash(){
lcd.clear();
lcd.setCursor(position-1,1); //move cursor one position left of the collision
lcd.write(3);//draw 'splatted' JumpMan
lcd.setCursor(wallPosition,1);
lcd.write(2); //draw the wall
delay(1000);
// Reset the variables to put the JumpMan back at the starting point
position = 0;
buttonState = 0;
jumpState = 0;
}
void startScreen(){
lcd.clear();
lcd.setCursor(2,0);//place cursor near the middle of Maker Screen
lcd.print("Press button 6");
lcd.setCursor(4,1);//Move to the next line and complete the message
lcd.print("to play!");
while (digitalRead(6) == HIGH){//while the button isn't pressed...
delay(10); //wait 10 ms and check the 'while' again
}
while (digitalRead(6) == LOW){ //while the button is pressed...
delay(10); //wait 10 ms and check the 'while' again
}
//After both 'while' loops have completed, clear the screen and complete
//the function
lcd.clear();
}
/*
* Now the player can prolong their life by grabbing extra hearts. You may
* see a pattern evolving here. To add a feature to the game, you are finding
* the exact spot where something should occur: a collision (or not) and using
* that moment in time to change a variable in the code. When all of these
* moments come together, you have a dynamic game with lots of moving parts.
*/
//(c) 2017 Let's Start Coding. License: www.letsstartcoding.com/bsdlicense
Heads up! You need our Chrome App to run this code.
Success!
Compile errors:
Serial port monitor:
Input:
As you near completion of the JumpMan Guided Build, you should be seeing the patterns that emerge when adding new features. The code is getting longer, but you have more structure that you can use to add new ideas more quickly. Without building it from the ground up, though, it would be tricky to distinguish how all of the pieces fit together.
